LEGRABOX C height (177mm) inner drawer pure - for use in cabinets 400mm wide, with 18mm cabinet sides. LEGRABOX pure – A full height glass front not only adds an extra design element to this slimline, sleek pull-out, it helps to view the drawer contents at a glance.
Supplied assembled for quick installation, the 40kg BLUMOTION S full extension runners feature a feather light glide and controlled soft close action, even when heavily loaded.
LEGRABOX can also be used handle-less, when combined with the mechanical TIP-ON latch set or SERVO-DRIVE, for the ultimate in effortless hands-free opening.
1 x Assembled C height drawer
1 x C height inner front with 138 x 10mm glass design element
2 x Side cover caps
1 x BLUMOTION S full extension soft close runners R+L
Blum lifetime guarantee
*0-Protrusion hinges (not included) are required to ensure inner drawers clear cabinet door.
Type of box: Sides LEGRABOX
Drawer side height: 177mm
Height required in cabinet: 193mm
Length required in cabinet: Side length + 3mm
Material: Steel sides, back and runners
Colour / finish: Orion grey or Stainless steel (Anti-fingerprint)
Connection drawer side to frontal: Clip-on fixing bracket, no need for tools
Front alignment: 3-Dimensional allows precise height +/- 2mm, side +/- 1.5mm, and tilt adjustment +/- 1.5mm
Require a different option? Give our helpful team a call.
*Please note our Stainless-Steel option is supplied, with a metal back panel finished in orion grey.
